SPECIFICATION :
Frame
Spark 3 Carbon / IMP technology / HMX
BB92 / Carbon SMC Link / Carbon swingarm
SW dropouts for Boost 148x12mm
TBC Trunnion box construction
Custom Chainguide
Fork
FOX 34 Float Factory Air / Kashima
FIT4 3-Modes with low speed adj. / 15x110mm QR axle
Tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control - Descend
DPS / EVOL / Kashima / Reb. Adj.
Travel 120 - 85 - Lockout / 165X45mm
Remote System
SCOTT TwinLoc Technology / below Bar Remote
3 modes / integ. Grip clam
Headset
Syncros FL1.5 Drop in / Tapered 1.5" - 1 1/8"
Ti bearing diameter size 42mm and 52mm
Rear Derailleur
Sram XX1 / Eagle 12 Speed
Front Derailleur
SCOTT Chainguide
Shifters
Sram XX1 Trigger
Brakes
Sram Level Ultimate Disc
180mm F & R / Centerline CLX Rotor
Crankset
Sram XX1 Eagle GXP Boost PF Carbon crankarm
QF 168 / 700 Series: 34T / 900 Series: 32T
BB-SET
Sram GXP PF integrated / shell 41x92mm
Handlebar
Syncros FL1.0 SL Carbon T-Bar
T shape flat / 9° / 740mm
Syncros Pro lock-on grips
Handlebar Stem
Syncros FL1.5 / Alloy 2014
Integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Garmin mount
Seatpost
Rock Shox Reverb Stealth
Inside hydraulic Remote system
31.6mm / S size 100mm / M, L & XL 125mm
Seat
Syncros XR1.0 SL / Carbon rails
Hub (Front)
Syncros XR1.0 CL / 15x110mm
Made by DT Swiss
Hub (Rear)
Syncros XR1.0 CL / Boost 148x12mm
RWS w/removable Lever / 36T Rachet System / XD
Made by DT Swiss
Chain
Sram PCXX1 Eagle
Cassette
Sram XX1 / XG1299 / 10-50 T
Spokes
DT Swiss Aero Comp
Rims
Syncros XR1.0 Carbon / 28H / Carbon rim
Tubeless ready
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx speed
